ASUS TUF GAMING B650-PLUS WIFI
Price Guarantee
Installment calculator
4,9%
interest
from 3.36 € monthly
ASUS TUF GAMING B650-PLUS WIFI
The ASUS TUF GAMING B650-PLUS WIFI motherboard, with its AMD B650 chipset and AM5 socket, offers a robust foundation for high-performance gaming rigs powered by AMD Ryzen Desktop processors. This ATX-format board combines military-grade components with an advanced power solution and a comprehensive cooling system for stable performance, even during demanding, extended gaming sessions. It supports four DDR5 memory modules with overclocking capabilities up to 6400MHz, features three M.2 slots (one with PCIe 5.0 support), and offers extensive expansion options thanks to two PCIe x16 slots, three PCIe x4 slots, one PCIe x1 slot, and four SATA III ports. Connectivity is handled by 2.5Gb Ethernet, WiFi 6, Thunderbolt (USB4), and a wide range of USB ports, including USB 3.2 Gen 2×2 Type-C. The integrated 7.1-channel sound card with DTS Audio Processing and two-way AI Noise Cancellation guarantees a top-tier audio experience.
AMD B650
Chipset
AMD AM5
Socket
ATX
Format
DDR5
Memory type
4×
Number of RAM slotsKey features of the ASUS TUF GAMING B650-PLUS WIFI motherboard
- AMD B650 chipset with support for AMD Ryzen 7000 series processors, DDR5 memory, and PCIe 5.0 technology, ensuring maximum performance and future compatibility
- 12+2+2 phase power design with 60A power stages and enlarged VRM heatsinks provides stable power delivery even during demanding overclocking
- ASUS OptiMem II technology for DDR5 with AMD EXPO profile support enables extreme transfer speeds and optimal memory performance
- WiFi 6 (802.11ax) with speeds up to 1.2Gb/s and 2.5-gigabit Ethernet ensure ultra-fast and stable low-latency network connectivity
- TUF cooling system with enlarged heatsinks on the VRM and M.2 slots, including the Q-Latch mechanism for easy, tool-free SSD installation
- Military-grade durability with SafeSlot Core+ construction, ESD Guards for up to 10kV electrostatic discharge protection, SafeDIMM connectors, and a stainless steel back I/O panel
Power and performance for demanding processors
The board uses a powerful 12+2+2 phase power design with DrMOS stages rated for 60 amps, which reliably covers the power demands of even the most powerful AMD Ryzen processors. Enlarged VRM heatsinks with a greater surface area effectively dissipate heat from the power circuits and chokes. The 8+4 pin ProCool connectors, built to strict specifications, ensure a perfect connection with the power supply cables and minimise impedance, preventing overheating and connection failures. Military-grade TUF chokes and capacitors with a 52% wider temperature tolerance and 2.5× longer lifespan than standard components guarantee long-term system stability. The integrated Digi+ VRM module optimises current delivery to the processor for maximum voltage purity and stability under all operating conditions.
High-speed memory and storage
Four DDR5 slots with ASUS OptiMem II technology allow you to reach extreme speeds of up to 6400MHz when overclocking, thanks to support for AMD EXPO profiles. For basic modules without EXPO support, the board offers the ASUS Enhanced Memory Profile (AEMP) feature, which unlocks higher performance even from entry-level memory. Advanced users will appreciate the extensive options for fine-tuning parameters directly in the UEFI BIOS. The storage subsystem features three M.2 slots – one with PCIe 5.0 support, reaching transfer speeds of up to 128Gbps, and two with PCIe 4.0. All are equipped with dedicated heatsinks to maintain optimal operating temperatures and consistent performance. All M.2 slots support NVMe RAID configurations, enabling maximum utilisation of available speeds. The innovative Q-Latch mechanism simplifies the installation and removal of M.2 drives without needing any tools.
Port selection
Storage
- Number of SATA III: 4
- Number of M.2: 3
- M.2 Slot - 1× M.2 PCI-E NVMe Gen5
- M.2 Slot - 2× M.2 PCI-E NVMe Gen4
- Features: RAID 0, RAID 1, RAID 10
USB ports
- Internal USB 2.0: 4 (2 headers)
- Internal USB 3.2 Gen 1: 2 (1 header)
- Internal USB-C 3.2 Gen 1: 1 (1 header)
- Rear USB 2.0: 4
- Rear USB 3.2 Gen 2: 2
- Rear USB-C 3.2 Gen 2: 1
- Rear USB-C 3.2 Gen 2x2: 1
Graphics
- HDMI 2.1
- DisplayPort 1.4
- Graphics outputs: HDMI, DisplayPort
Sound
- Number of channels: 7.1
- Rear connectors: 5× 3.5mm
Other
- Rear: BIOS FlashBack button, Wi-Fi antenna
- Power: 24-pin, 1× 8-pin, 1× 4-pin
- Cooling: Number of PWM FAN (4-pin) - 6, Water pump - 4-pin
- Internal: Chassis Intrusion (JCI), RGB LED (4-pin), Addressable RGB (3-pin)
Choosing a motherboard
When choosing a motherboard, it's important to pay particular attention to the motherboard socket type, format, and chipset. These are the most crucial parameters, ensuring the board is compatible with the processor, expansion cards, and other components. The specific socket determines your choice of a suitable processor, while the remaining connectors dictate which other components you'll need for your future computer.Specifications
Socket and chipset
Format & functions
Memory
Advanced parameters
Connectors
Series
Compatibility
Colour
| Code: | ACb650tpw |
| Warranty: | 36 months |
| Links: | Producer's Website: |
