MSI MPG Z790 CARBON WIFI
The MSI motherboard is based on the Intel Z790 chipset, and it uses the Intel 1700 socket to accommodate the processor. As is the standard, it is also equipped with a sound card made for 7,1 channels. You will be able to utilise the network connection module with the practical Wi-Fi connection options. It is a larger motherboard for high-range PC configs, which require multiple cards and complex cooling. If you want to build a PC with this model, it is neccessary to use a compatible ATX format case.
MSI MPG Z790 CARBON WIFI Motherboard Key Features
- Intel 1700 socket and the Intel Z790 chipset
- MSI MPG Z790 CARBON WIFI format: ATX
- Integrated audio card for 7,1 channels
- DDR5 RAM type with DIMM design
- The motherboard can accommodate 4 × dual-channel memory modules
- RAID controller for greater data security
MSI MPG Z790 CARBON WIFI Motherboard Connectivity
Computer memory is something you obviously can't do without , so this MSI motherboard is equipped with 4 RAM slots. You can pair it with DDR5 type DIMM operating memory. You can hook them up in dual-channel mode. This motherboard is compatible with models with a clock speed of up to 7600 MHz. The device also features a RAID controller for in-depth data security via independent drive management.
MSI MPG Z790 CARBON WIFI Connectors
This motherboard accommodates 2 graphics cards with PCI Express 16x slots. The internal interface also includes a total of 5 popular M.2 slots.
What Else Can the MSI MPG Z790 CARBON WIFI Motherboard Do?
- The motherboard comes with an integrated Realtek ALC4080 sound card
- Other notable advantages encompass features such as RAID controller
- External interfaces: Jack, RJ-45 (LAN) 2.5Gbps, S/PDIF , USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C 3.2 Gen 2, USB-C 3.2 Gen 2x2 and HDMI 2.1
- Supported internal interfaces: ARGB LED Header, RGB LED Header, Serial ATA III, TPM header, USB 2.0 header, USB 3.2 Gen 1 header, USB-C 3.2 Gen 2x2 header, M.2 PCIe 5.0, PCIe 5.0 x16, PCIe 4.0 x16, PCIe 3.0 x1 and M.2 PCIe 4.0 + SATA
- Maximum supported RAM clock speed: 7600 MHz
- Serial ATA III: 6 ×
Specifications
Socket and chipset
Format & functions
Memory
Advanced parameters
Connectors
Series
Compatibility
| Code: | AAz790mcw |
| Links: | Producer's Website: |
| Manufacturer information |
Micro-Star International Co Ltd. C/O MSI Computer Europe BV, Science Park Eindhoven 5706, 5692 ER, Son, Netherlands, [email protected] The Taiwanese company MSI (Micro-Star International) has earned a solid place in the world of IT, mainly producing motherboards for desktop computers. However, it also produces high quality graphics cards, barebone computers, notebook computers, networking products, servers, and many other computer components. MSI products support the latest technologies and provide the performance necessary for all applications. Recently, the company has begun making a name for itself in the growing segment of gaming notebooks.
|
